Enerco Technical Products, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 866-447-2194
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
UNVENTED NATURAL GAS FIRED ROOM HEATER
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or loss of life.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
-WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegassupplier’sinstructions.
• If you cannot reach your gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for
Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is
not convertible for use with any other gas.
Blue Flame Heaters
HSSVFBF30NGBT
HSSVFBF20NGBT
Plaque Heaters
HSSVFRD20NGBT
HSSVFRD30NGBT
OPERATING INSTRUCTIONS
ANDOWNER’SMANUAL
Model #
HSSVFRD20NGBT
HSSVFRD30NGBT
HSSVFBF20NGBT
HSSVFBF30NGBT
READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and
follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has
not read these instructions to assemble, light, adjust or operate the heater.
13 Installation Instructions and Owner’s ManualUnvented Natural Gas Vent Free Room Heaters
PAGE LEFT INTENTIONALLY BLANK
15 Installation Instructions and Owner’s ManualUnvented Natural Gas Vent Free Room Heaters
OBSERVED SYMPTOM POSSIBLE CAUSE REMEDY
Burner does not light after
ODS/pilot is lit
Burner orifice is clogged Clean burner orifice (see Cleaning and Maintenance on page
11), or replace burner orifice
Burner orifice diameter to small Replace burner orifice
Inlet gas pressure is too low Contact local gas company
Delayed ignition of burner
Manifold pressure is too low Contact local gas company
Burner orifice is clogged Clean burner orifice (see Cleaning and Maintenance on page
11), or replace burner orifice
Burner backfiring during
operation
Burner orifice is clogged or damaged Clean burner orifice (see Cleaning and Maintenance on page
11), or replace burner orifice
Burner damaged Replace burner
Gas regulator defective Replace gas regulator
Burner plaque(s) does not
glow [Infrared Only]
Plaque damaged Replace burner
Control knob set between locked
positions
Turn control knob until it locks at desired setting.
Inlet gas pressure is too low Replace gas regulator
Slight smoke or odor
during initial operation
Residues from manufacturing process Problem will stop after a few hours of operation
Heater produces a
whistling noise when
burner is lit
Turning control knob to HI position when
burner is cold
Turn control knob to LO position and let warm up for a minute
Air in gas line Operate burner until air is removed from line have gas line
checked by local gas company
Air passageways on heater blocked Observe minimum installation clearances (see Figure 4 page 6)
Dirty or partially clogged burner orifice. Clean burner orifice (see Cleaning and Maintenance on page
11), or replace burner orifice
White powder residue
forming within burner box
or on adjacent walls or
furniture
When heated, vapors from furniture
polish, wax, carpet cleaners, etc., turn
into white powder residue
Turn heater off when using furniture polish, wax, carpet cleaner
or similar products
Heater produces unwanted
odors.
Heater burning vapors from paint,
hair spray, glues, etc. See IMPORTANT
statement on page 14
Ventilate room. Stop using odor-causing products while heater
is running.
Gas leak. See WARNING statement at top
of page 14
Locate and correct all leaks (see Checking Gas Connections,
page 9)
Heater shuts off in use
(ODS operates)
Not enough fresh air is available Open window and/or door for ventilation
Low line pressure Contact local gas company
ODS/pilot is partially clogged Clean ODS/pilot (see Cleaning and Maintenance, page 11)
Gas odor even when
control knob is in OFF
position
Gas leak. See WARNING statement at top
of page 14
Locate and correct all leaks (see Checking Gas Connections,
page 9)
Control valve is defective Replace control valve
Gas odor during
combustion
Foreign matter between control valve
and burner
Take apart gas tubing and remove foreign matter
Gas leak. See WARNING statement at top
of page 14
Locate and correct all leaks (see Checking Gas Connections,
page 9)
Heater produces a clicking/
ticking noise just after
burner is lit or shut off
Metal expanding while heating or
contracting while cooling
This is common with most heaters. If noise is excessive, contact
qualified service person
Moisture/condensation
noticed on windows
Not enough combustion/ventilation air Refer to Fresh Air for Combustion and Ventilation page 3
through 5.
