Sida 1/2
*SHIPPING
WEIGHT
MINIMUM
12 (.3)
18 (.460
22.25 (.57)
34.25 (.87)
46.25 (1.17)
58.25 (1.48)
70.25 (1.78)
82.25 (2.09)
94.25 (2.39)
106.25 (2.70)
118.25 (3)
*SHIPPING
WEIGHT
MAXIMUM
18 (.46)
24 (.61)
34.25 (.87)
58.25 (1.48)
70.25 (1.78)
82.25 (2.09)
94.25 (2.39)
106.25 (2.70)
118.25 (3)
130.25 (3.31)
142.25 (3.61)
*SHIPPING
WEIGHT
MODEL#
ADD012018
ADD018024
ADD0203
ADD0305
ADD0406
ADD0507
ADD0608
ADD0709
ADD0810
ADD0911
ADD1012
MODELS: ADD012018, ADD018024, ADD0203, ADD0305, ADD0406, ADD0507, ADD0608, ADD0709, ADD0810, ADD0911, ADD1012
SPECIFICATIONS
..attached to
round beam.
..attached to
I-beam.
L
Multi-Display Carousel models
MD220, MD320, MD390, MD420,
MD520, MD620, MD227, MD297,
MD327, MD397, MD427, MD527,
MD627
CEILING
BALANCED MAXIMUM LOAD CAPACITY for all
Extension Columns for Multi-Display Mounts: 800 lb (363 kg)
Shipping weight based on single unit shipment.
Per unit shipping weight may be less for bulk orders.
Balanced Maximum Load Capacity includes the combined weight
of the Multi-Display Carousel or Dual Jumbo Mount (page 2) and all
equipment (TVs and VCRs). All TVs and VCRs must be of the
same model for proper balance/stability.
Extension
Column
*SHIPPING
WEIGHT
lb (kg)
4.5 (2)
3 (1.4)
8 (3.6)
9.8 (4.4)
13 (5.9)
16.5 (7.5)
18 (8.2)
19.5 (8.8)
21 (9.5)
22.5 (10.2)
28 (12.7)
**
**
*
Peerless Industries, Inc.
3215 W. North Ave. phone: (708) 865-8870
Melrose Park, IL 60160 fax: (708) 865-2941
ISSUED: 8-25-94 SHEET NO:139-9507-3 8-19-03 page 1 of 2
TECHNICAL DATA SHEET
EXTENSION COLUMN FOR MULTI-DISPLAYTM MOUNTS
Protected by U.S. Patent no. 5127617 and 5487524. International patents pending.
Truss Ceiling Decoupler
model DCT300...
Structural Ceiling
Decoupler model DCS400
Multi-Display Carousels, Multi-Display Dual
Jumbo Mounts, Structural Ceiling Decoupler, and
Truss Ceiling Decoupler are sold separately. For
additional information see Technical Data Sheets
for these products.
The Extension Column for Multi-Display Mounts
is one of three elements required for Multi-
Display Ceiling Mount installations. It is available
in several lengths which are adjustable at 1"
increments (see specifications, above right).
See page 2 for
Multi-Display Dual
Jumbo Mounts
Architects specifications:
The extension column shall be a Peerless model ADD_____ . It shall offer a ___ inch
range of height adjustment at 1" increments. It shall be constructed of steel tubing and
finished in scratch resistant black fused epoxy. It shall be UL Listed. Assembly and
installation shall be done according to the instructions provided by the manufacturer.
4.5" (114mm) 5.3" (135mm) 4.7" (119mm)
8.8" (224mm)
*SHIPPING
WEIGHT
lb (kg)
5 (2.3)
5.5 (2.5)
8.2 (3.7)
13.3 (6)
16 (7.3)
21 (10)
22 (11)
24 (11)
26 (12)
30.3 (13.7)
34 (15.4)
LENGTH (L) - adjustable at
1"increments
in. (meter)
R
EXTENSION COLUMN FOR
MULTI-DISPLAY MOUNTS
retaining collar
adjuster tube
extension pipe
The "tube in tube" design
of the Adjustable Exten-
sion Column allows it to
be adjusted, within its
specified range, at 1 inch
(25mm) increments. Two
bolts and two lock nuts
are provided. One locks
the extension column
securely to the ceiling
decoupler. The other
securely locks the two
tubes together at the
desired length. The
retaining collar is used to
attach the Multi-Display
Carousel or Multi-Display
Dual Jumbo Mount to the
end of the extension
Pipe.
Multi-Display Dual Jumbo Mount models
MDJ630, MDJ640, MDJ640D, MDJ650,
MDJ650D, MDJ660
..attached to
round beam.
CEILING
Extension
Column
Truss Ceiling Decoupler
model DCT300...
Structural Ceiling
Decoupler model DCS400
L
4.5" (114mm) 5.3" (135mm) 4.7" (119mm)
..attached to
I-beam.
B
A
C
page 2 of 2
ISSUED: 8-25-94 SHEET NO:139-9507-3 8-19-03
The Extension Column for Multi-Display
Mounts is one of three elements required for
Multi-Display Ceiling Mount installations. It is
available in several lengths which are
adjustable at 1" increments (see specifica-
tions, page1). Multi-Display Carousels, Multi-
Display Dual Jumbo Mounts, Structural
Ceiling Decoupler, and Truss Ceiling
Decoupler are sold separately. For additional
information see Technical Data Sheets for
these products.
See
"Specifications"
(page 1).
Note: For dimensions A, B, C, H and W see TD Sheet for Multi-Display Dual Jumbo Mount .
W
H
See page 1 for Multi-Display Carousels
MODELS: ADD012018, ADD018024, ADD0203, ADD0305, ADD0406, ADD0507, ADD0608, ADD0709, ADD0810, ADD0911, ADD1012
bolt
lock nut
ID 1.32" (34mm) x
OD 1.56" (40mm)
adjuster tube
TOP VIEW
ID 1.61" (41mm) x
OD 1.90" (48mm)
extension pipe
© 2003 Peerless Industries, Inc. All rights reserved.
Peerless is a registered trademark of Peerless Industries, Inc.
All other brand and product names are trademarks or registered trademarks of their respective owners.
