Amplifier Owner’s Manual

Models: RX2 750.5 ● RX2 400.4

Amplifier

Manual

The RX2-series ampliers are the next evolution of the

reliable and great sounding RX series. With a new, more

efcient circuit design, we have increased power output

while decreasing chassis size (most models). These ampliers

will be the reference for style and value in any installation.

Built with the legendary Phoenix Gold reliability, they feature

heavy duty heatsinks, robust unregulated power supplies,

and oversized direct input power and speaker terminals.

They also sound sweet thanks to the audiophile grade

output transistors. We made upgrading your stock system

easy by allowing high level inputs so you can keep the OEM

radio, and still upgrade the sound. RX2-series ampliers are

ready to impress with their effortless ability to provide power

and clarity while keeping the chassis at a convenient size

for any installation. The devil is in the details, so it just made

sense that we allow the PG name plate to be removed and

turned to match the orientation you might need for your

install because we know your going to want show off your

system and make all you’re friends jealous.

• Class-D Topology RX2 750.5

• Class-A/B Topology RX2 400.4

• Small Footprint Chassis Design

• Robust Unregulated Power Supplies

• Rotatable Name Badge for Installation Flexibility

• High Level Inputs for Easy OEM Integration

• Remote Bass Controller Included (RX2 750.5)

• Audio Precision® Quality Control Verication

Features

Amplifier Owner’s Manual

SPECIFICATIONS

IMPORTANT: A power birth certicate is included for each amplier. RX2 ampliers are

conservatively rated and will exceed their RMS power rating shown here. All RMS power

ratings and measurements are at 14.4 volts with no more than 1% THD.

SPECIFICATIONS

Remote Bass Controller:

Under dash or console mountable level controller. Fine tune your bass

output with a simple turn of the precision controller. Amplier Status LED for

easy reference of amplier. 16ft of cable included.

RX2 750.5 SPECIFICATIONS

RMS Power Ratings listed at less than 1% THD @ 14.4v

Number of Channels: 5

4Ω: CH 1-4 60W x 4

2Ω: CH 1-4 90w x 4

4Ω: CH 5 250W x 1

2Ω: CH 5 400w x 1

3CH Mode: 1+2 4Ω Bridged & 3+4 4Ω Bridged + CH 5 4Ω 180W x 2 + 250W x 1

3CH Mode: 1+2 4Ω Bridged & 3+4 4Ω Bridged + CH 5 2Ω 180W x 2 + 400W x 1

Total RMS Power (Sum of rated power): 760W

Bridgeable: Yes

Crossover Mode: FLAT/HP/LP

CH 1-4: 50Hz - 200Hz @ 12dB / Oct Linkwitz Riley

CH 5: 50Hz - 200Hz @ 12dB / Oct Linkwitz Riley

Subsonic: 10Hz – 40Hz

Input Channels: 2CH F, 4CH F/R or 6CH F/R/S

Input Mode: Unbalanced

Input Sensitivity: .2v - 6v Unbalanced RCA Low-Level

Processing: Bass Boost 0dB +6dB +12dB @45hz

Signal to Noise (@ CEA Standard): >80dB

Frequency Response: Full Range 10-40k

Sub 15-200Hz

Topology Class D

Heatsink Type: Extruded Aluminum

Cooling Type: Radiation

Operating Voltage: 8V to 16V

Switchable Auto-Turn On: Yes

Power Supply Type: Unregulated

Onboard Thermal Management

Power Terminal: 4 Gauge

Speaker Terminal: 10 Gauge

Onboard Fusing: 3 x 35A ATC

Recommended Inline Fusing: 80A

Dimensions (L x W x H): 11.81” x 8.11” x 1.98”

300mm x 206mm x 50.5mm

11. 8 1in /3 0 0.00 mm

8 .11 in /20 6 .0 0 mm

1.98 in / 50. 5 m m

8.11in /206.00 mm

Amplifier Owner’s Manual

RX2 750.5

MULTI-CHANNEL POWER AMPLIFIERS

Features listed below are in order from left to right on

the amplier.

REMOTE LEVEL CONTROL

This port is for connecting the remote subwoofer level

control. This allows up to 20dB of volume adjustment.

This is not a bass boost, it controls the level of the low

pass signal.

MODE - (FRONT, REAR AND SUB INPUTS)

Mode allows either 2ch, 4ch or 6(5) channel inputs

to be used to drive the amplier and no use of

Y-connectors are needed.

● Select if you only have 2ch of signal. The FRONT

amplier will split the signal internally and send to Rear

and Sub channels.

● Select if you have 4ch of signal. The amplier F+R

will split the signal internally from the front and rear

channels and send to Sub channel.

● Select if you have 6ch of signal. The amplier F+R+S

will sum the 2ch sub input to create channel 5. This

setup will also have full control from your source unit for

front rear and sub levels.

X-OVER (REAR)

Full HPF or is selectable. Select Full if you are using an

outboard crossover/processor or you wish the Rear

channels to amplify full range signal. Select HPF (High

Pass Filter) to activate the internal crossover which is

continuously variable from 50Hz to 200Hz.

SUBSONIC

Controls the subsonic highpass lter crossover point.

Continuously variable from 10Hz to 40Hz to remove low

frequencies to increase system efciency, output and

speaker protection on the Sub channel (5).

GAIN (REAR)

Used to adjust the input sensitivity to match the input

level signal on the Rear channels. Continuously variable

from 0.2V to 6V. Adjust this with the help of a DMM and

a test signal or an Oscilloscope. See System Tuning

section for setup instructions.

REAR, FRONT AND SUB INPUTS

Connect preamp signal cables from headunit to

these inputs. These inputs are controlled by the MODE

switch. Be sure to select the correct mode for the

amount of inputs you will be using for your installation.

GAIN (SUB)

Used to adjust the input sensitivity to match the

input level signal on the Sub channels. Continuously

variable from 0.2V to 6V. Adjust this with the help of a

DMM and a test signal or an Oscilloscope. See System

Tuning section for setup instructions.

HPF (HIGH PASS FILTER - FRONT)

Controls the highpass crossover point for the Front

channels. Continuously variable from 50Hz to 200Hz.

BASS EQ (SUB)

Selectable Bass EQ with boost adjustment to 0dB, 6dB

or 12dB.

X-OVER (FRONT)

Full HPF or is selectable. Select Full if you are using an

outboard crossover/processor or you wish the Front

channels to amplify full range signal. Select HPF (High

Pass Filter) to activate the internal crossover which is

continuously variable from 50Hz to 200Hz.

LPF (LOW PASS FILTER - SUB)

Controls the lowpass crossover point for the SUB

channel. Continuously variable from 50Hz to 200Hz.

GAIN (FRONT)

Used to adjust the input sensitivity to match the input

level signal on the Front channels. Continuously

variable from 0.2V to 6V. Adjust this with the help of a

DMM and a test signal or an Oscilloscope. See System

Tuning section for setup instructions.

HPF (HIGH PASS FILTER - FRONT)

Controls the highpass crossover point for the Front

channels. Continuously variable from 50Hz to 200Hz.
