Sida 1/12
© 2021 Phoenix Gold • www.phoenixgold-eu.com
POWERFUL 24VOLT CLASS D AMPLIFIERS
SUITABLE FOR 24VOLT SYSTEMS
Model: ZT6004 / ZT15001
• - powers on the amp when audio signal is suppliedHigh Level Auto-Turn On
• - compatible with aftermarket/original source unitsOEM Connection Ready
• Integrated Fan - regulates temp. for sustained performance (ZT15001 only)
• - control bass level with included ZRBC Remote Bass Ready (ZT15001 only)
• - versatile connectivity to suit any vehicleHigh & Low Level Inputs
• - enables maximum current supplyHeavy Duty Connector Block
• - protection against thermal damage, 4-Way Protected Circuit
reversed power, speaker polarity and low voltage
SPECIFICATIONS
All specications subject to change without notice.
ZT
24VOLT
© 2021 Phoenix Gold | A Brand of AAMP Global
www.phoenixgold-eu.com
ZT6004 / ZT15001 - ZT-Series Ampliers
ZT6004 ZT15001
Class Class D Class D
Frequency
Response 20Hz-20KHz 20Hz-400Hz
Dims (LxWxH(mm)) 253 x 160 x 48 333 x160 x 48
RMS Power
Ratings
175W x 4 @ 2ohm
100W x 4 @ 4ohm
350W x 2 @ 4ohm bridged
1600W x 1 @ 1ohm
1150W x 1 @ 2ohm
650W x 1 @ 4ohm
Signal to
Noise Ratio >96dB >96dB
High & Low Pass
Crossover 12dB per Octave 24dB per Octave
Subsonic Filter N/A 12dB per Octave
Crossover
Range 50Hz-250Hz 50Hz-400Hz
Subsonic
Crossover Range N/A 10Hz-55Hz
Bass Boost
@ 45Hz N/A 0 to +18dB
High & Low Level
Input Range 0.2Volts to 10Volts 0.2Volts to 10Volts
Minimum Load
Impedance
2ohm Stereo &
4ohm bridged 1ohm
Note:
Phoenix Gold Ampliers have a minimum load impedance
of 2ohm per channel 4ohm bridged (& 1ohm for monoblocks)
© 2021 Phoenix Gold • www.phoenixgold-eu.com
ZT6004 / ZT15001 - ZT-Series Ampliers
Installation Warnings
1. Ensure the +24V lead is disconnected from the battery before you
connect any new equipment
2. Ensure that the amplier mounting location and holes will not interfere
with the petrol tank, brake lines or electrical wiring.
3. Ensure the amplier is securely fastened to the vehicle to prevent the
amplier moving and causing damage in the event of an accident
4. Ensure all wiring is protected from sharp objects and from pinching or
crushing which could result in damage to the audio system
5. Ensure the mounting location has sufcient air ow around the
amplier. If the amplier is mounted in an enclosed space a 3” fan
with ducting should be used to assist with cooling.
6. Do not mount any amplier on a subwoofer enclosure as extended
exposure to vibration may cause damage to the amplier.
7. Ensure the minimum recommended gauge wire/cable or larger for all
amplier connections
8. Appropriate mounting is very important for prolonged life
expectancy of any amplier. Select a location that provides
protection from moisture. Keep in mind that an amplier should never
be mounted upside down. Upside down mounting will compromise
heat dissipation through the heat sink and could engage the thermal
protection circuit.
