Sida 1/32

Models: Z150.2 - Z300.1 - Z300.4 - Z600.5 - Z1000.1

Z-Series

Ampliers

Integrated Cooling Fan - Regulates amplier temperature for sustained performance

High & Low Level Inputs - Versatile connectivity to suit any vehicle (ZRHC High Level Adaptor required) - sold separately

OEM Connection Ready - Compatible with aftermarket or original t source units

High Level Auto-Turn On - Powers on the amplier when an audio signal is supplied (via the ZRHC High Level Adaptor)

Remote Bass Ready - Control the Bass Level with the ZRBC (sold separately)

4-Way Protection Circuit - Thermal / Reversed Power and Speaker Polarity / Low Voltage

Heavy Duty Connector Block - Enables Maximum Current Supply

Ventilateur de refroidissement intégré - Régule la température de l’amplicateur pour une performance soutenue

Entrées haute et basse - Connectivité polyvalente pour tous les véhicules (ZRHC Haut niveau Adaptateur

requis) - vendu séparément

Prêt pour une connexion OEM - Compatible avec les unités d’origine et de rechange.

Mise sous tension automatique à haut niveau - Allume l’amplicateur lorsqu’un signal audio est détecté

(via l’adaptateur ZRHC de haut niveau)

Prêt pour la commande des graves à distance - Contrôle du niveau des graves avec le ZRBC (vendu séparément)

Circuit de protection 4-voies - Puissance thermale/inversée et haut-parleur Polarité/Basse tension.

Bloc de connecteur robuste - Permet une alimentation maximale

Ventilador de Refrigeración Integrado - Regula la temperatura del amplicador para mantener su buen rendimiento

Entradas de Alto y Bajo Nivel - Conectividad versátil para adaptarse a cualquier vehículo (Se requiere de un

Adaptador ZRHC de Alto Nivel) – El mismo se vende por separado

Conexión de OEM Lista - Compatible con unidades originales o de segunda mano.

Encendido Automático de Alto Nivel - Se enciende el amplicador cuando se suministra una señal de audio (A través

del Adaptador de Alto Nivel ZRHC)

Control Remoto de Bajos - Controle el nivel de graves con el ZRBC (se vende por separado)

Circuito de Protección de 4 vías - Potencia térmica / retroceso y altavoz Polaridad / baja tensión.

Bloque de conector robusto - Permite una máxima potencia

Les amplicateurs de la série Z

Los amplicadores series Z

CARACTÉRISTIQUES

FEATURES

CARACTERÍSTICAS

Z-Series Ampliers

Z300.4 Z150.2 Z300.1 Z600.5 Z1000.1

Class Class A/B Class A/B Class A/B Class A/B Class D

Power (MAX) 1200 Watts 600 Watts 1200 Watts 2400 Watts 2000 Watts

Frequency

Response

20Hz-20KHz 20Hz-20KHz 20Hz-400Hz 20Hz-20KHz 20Hz-300MHz

Dimensions (mm) 312x186x49 232x186x49 312x186x49 372x186x49 312x186x49

RMS Power

Ratings

60W x 4 @ 4ohm

75W x 4 @ 2ohm

150W x 2 @ 4ohm

bridged

60W x 2 @ 4ohm

75W x 2 @ 2ohm

150W x 1 @ 4ohm

bridged

200W x 1 @ 4ohm

300W x 1 @ 2ohm

60W x 4 @ 4ohm

+1 x 200W @ 4ohm

75W x 4 @ 2ohm

+1 x 300W @2ohm

150 x 2 @ 4ohm

bridged

+1 x 300 @ 2ohm

400w p2-x1 @ 4 ohm

700w x 1 @ 2 ohm

1000w x 1 @ 1 ohm

Signal to

Noise Ratio

>50dB >50dB >50dB >50dB >90dB

High & Low Pass

Crossover

12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave

Subsonic Filter N/A N/A 12dB per Octave 12dB per Octave 12dB per Octave

Crossover

Range

50Hz-250Hz 50Hz-250Hz 50Hz-400MHz 50Hz-250Hz (CH1,2,3,4)

50Hz-400Hz (Sub-

woofer)

30Hz to 300Hz

Subsonic

Crossover Range

N/A N/A 10Hz-40Hz 10Hz-40Hz 10Hz to 55Hz

Bass Boost

@ 45Hz

N/A N/A 0 to +18dB 0 to +18dB 0 to +18dB

Low Level

Input Range

0.35 Volts

to 10 Volts

0.35Volts to

10 Volts

0.35 Volts to

10 Volts

0.35 Volts to

10 Volts

200 millivolts to 8 volts

High Level

Input Range

1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 200 millivolts to 20 volts

Minimum Load

Impedance

2 ohm Stereo &

4 ohm bridged

2 ohm Stereo &

4 ohm bridged

2 ohm 2 ohm Stereo &

4 ohm bridged

1 Ohm

Note:

Phoenix Gold Ampliers have a minimum load impedance

of 2ohm per channel 4ohm bridged

(except Z1000.1 - which is 1 Ohm)

Z-Series Ampliers

Z150.2 - Z300.1 - Z300.4 - Z600.5 - Z1000.1

Installation Warnings

1. Ensure the +12V lead is disconnected from the battery before you

connect any new equipment

2. Ensure that the amplier mounting location and holes will not interfere

with the petrol tank, brake lines or electrical wiring.

3. Ensure the amplier is securely fastened to the vehicle to prevent the

amplier moving and causing damage in the event of an accident

4. Ensure all wiring is protected from sharp objects and from pinching or

crushing which could result in damage to the audio system

5. Ensure the mounting location has sufcient air ow around the

amplier. If the amplier is mounted in an enclosed space a 3” fan

with ducting should be used to assist with cooling.

6. Do not mount any amplier on a subwoofer enclosure as extended

exposure to vibration may cause damage to the amplier.

7. Ensure the minimum recommended gauge wire/cable or larger for all

amplier connections

8. Appropriate mounting is very important for prolonged life

expectancy of any amplier. Select a location that provides

protection from moisture. Keep in mind that an amplier should never

be mounted upside down. Upside down mounting will compromise

heat dissipation through the heat sink and could engage the thermal

protection circuit.
