Sida 1/2
ILC19 In line
Level Control
Rolls
12/15
ILC19 In line
Level Control
The SLC19 is a simple device designed to
control balanced XLR audio signals such
microphones, or anywhere an XLR line level
control is desired.
• Balanced XLR Input and Output
• Level Volume control
75889 00191
6 4
INTRODUCTION
Thank you for your purchase of the ILC19 In line Level Control.
The ILC19 is a simple device designed to control XLR line-level
audio signals such as those connected to powered speakers, computer
speakers, microphones, or anywhere an in line level control is
desired.
INSPECTION
1. Unpack and Inspect the ILC19 package
Your ILC19 was carefully packed at the factory in a protective carton.
Nonetheless, be sure to examine the unit and the carton for any signs
of damage that may have occurred during shipping. If obvious physical
damage is noticed, contact the carrier immediately to make a damage
claim. We suggest saving the shipping carton and packing materials for
safely transporting the unit in the future.
WARRANTY
For information on the Rolls One Year Limited Warranty, and
to register this product, visit our website at www.rolls.com
DESCRIPTION
FRONT PANEL
INPUT/OUTPUT: Female XLR Input jack.
LEVEL: Adjusts the level of the signal.
REAR PANEL
INPUT/OUTPUT: Male XLR Output jack.
OPERATION
The ILC19 is an in line level control for XLR balanced signals. The
unit can operate with the Female jack on the front as an input,
with the Male jack on the rear being its output. It can also be
used in reverse meaning that the rear Male jack can be the input,
with the front Female jack being the output.
The ILC19 can be used with a MIC or LINE level balanced signals.
Specs:
Max Out: +30 dB
Max In: +30 dB
Input Impedance: 5k Ohm balanced
Output Impedance: 5k Ohm balanced
Weight: .35 lbs.
Size: 2.25” x 2.25” x 1.55”
DO NOT CONNECT THE ILC19 TO ANY SPEAKER LEVEL
OR POWERED SIGNAL. DOING SO WILL DAMAGE THE
UNIT.
