Packing List
User Manual
用户手册
Professional Condenser Microphone
专业级电容麦克风
Soundbird T3L
Statement
Please read this manual carefully before using and strictly operate and store in
accordance with the instructions. Please save it for your future reference.
If the user manual can not help you to solve problems, please ask your retailer
for help or email us: .info@saramonic.com
Cautions
1. expose it to Do not use the unit under moisture condition or water, don’t
rain. Please store it in a cool, dry place.
2. Please use and store it in normal temperature. Do not move it from
overheated to supercooled condition frequently as well as keep away from
heat sources such as heater or oven.
3. When using and storing, please pay attention to dust and moisture.
4. Be careful to violent collision.
5. To avoid acoustical feedback, do not hold the microphone close to the
loudspeakers.
6. For the best pick-up pattern, do not hold your hand against the microphone
cover.
6. Do not exceed the maximum load capacity.
Introduction
Saramonic Soundbird T3L is a super-long directional shotgun microphone
features a super-cardioid polar pattern, built-in rechargeable battery, 75
Hz/150 Hz low cut switch, +6 dB high frequency boost, -10 db PAD and power
button.
Soundbird T3L is very fit in several environments for applications such as DSLR
video making, ENG, filmmaking, field recording, sound design, and broadcast
applications.
声明
请在使用前仔细阅读本手册，并严格按照说明进行操作和存储。请保存以供将来参
考。如果用户手册不能帮助您解决某些问题，请向零售商寻求帮助或给我们发送电子
邮件：info@saramonic.com。
注意事项
1. 请勿在水下使用本机，也不要使其受到雨淋。 请存放在阴凉干燥处。
2. 请在常温下使用和存放。 请经常将其从过热状态移至过冷状态，并远离加热器和烤
箱等热源。
3. 使用和存放时，请注意防尘和防潮。
4. 注意剧烈碰撞。
5. 为避免声音反馈，请勿将麦克风靠近扬声器。
6. 为获得最佳拾音模式，请勿将手放在麦克风上。
Saramonic Soundbird T3L 是专业级超心型加长版枪式麦克风，内置锂电池并且有强大
功能支撑，75Hz/150Hz低切键切换，+6dB高频增益，-10dB衰减，保证录制过程顺利
进行。
Saramonic Soundbird T3L 是专业级超心型加长版枪式麦克风，强大功能支撑，75Hz/
150Hz低切键切换，+6dB高频增益，-10dB衰减，保证录制过程顺利进行。适用于视频
拍摄，电影制作，现场录制，广播等场景。
Power by Built-In Battery by 48V Phantom Power Low Power
Power Indicator Blue Light Green Light Red Light
Feature
• -10dB Pad
Attenuates the microphone input to allow for the recording of loud sounds
without clipping.
• 75Hz/150Hz High Pass Filter
Reduces low frequency and infrasonic rumble from HVAC systems indoors or
street traffic outdoors from over-powering the recording.
• High Frequency Boost
Restores some of the high frequency content that is often lost when a blimp
or furry windshield is placed over the microphone and improves the
intelligibility of recorded speech.
• High Frequency Boost
The built-in battery supports at least 150 hours operation.
• Battery Indicator
If you would like to check the battery level during recording, double press the
Power button, the 5 indicators will show the remaining battery capacity. If
5 indicators are all blue, the battery is full.
• Supplied with foam windshield, mic clip and shock mount, XLR Cable and
MicroUSB charging cable
Power Supply
The Soundbird T3L can be po rwe ed via
• e b ltTh ui -in lithium b rattery; o
• 48V phantom power, which is supplied by your camera or recording
devices (such as Sara R-Pmonic S AX2,
S
R-AX104, S
R-AX107.) When
phantom power is applied, the built-in battery will not be used, or
charged.
75 Hz high pass filter button / 75Hz低切键
150 H pz high ass filter button / 150Hz低切键
+6 d fr t B high equency boos / +6dB高频增益
-10 db PAD / -10dB衰减
Power button / 电源键
Built-in L att y i-ion b er / 内置锂电池
Foam windshield / 防风棉
XL tR ou put / XLR输出
Micro USB input
Micro USB输入
Mic clip
麦克风支架
Shock mount
麦克风防震支架
MicroUSB cable
MicroUSB 充电线
XLR cable
XLR 输出线
www.saramonic.com
Saramonic is a trademark registered and owned by Shenzhen DSQN Investment CO., LTD.
COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL ( A brand of DSQN )
Room 2009, Shenzhou Bairuida Bldg, Banxuegang Road, Bantian Street, Longgang District,
Shenzhen, China 518129 Tel: 400-61 1096 Email: info@saramonic.com3-
深圳市大盛青牛投资有限公司
广东省深圳市龙岗区坂雪岗大道百瑞达大厦A栋2009室
全国服务热线：400-61 10963-
中国制造 Made in China
Please follow our WeChat account for more details.
扫描二维码关注枫笛Saramonic微信公众号。
For better recording experience, the app-lication
SmartRecorder is recommended.
为获得更好的录制体验，推荐使用枫笛 Saramonic 自主研发
应用软件 SmartRecorder。
Packing List
• Soundbird T3L Microphone
• Micro USB Cable
• SR-SMC1 Mic Clip
• SR-SMC3 Shock Mount
• Foam Windshield
• 60cm (1.9')XLR Cable
POLAR PAT NTER
Specification
Acoustic Principle Line gradient
Directional Pattern Super-cardioid
Frequency Range 35 to 20k Hz (selectable HPF 75/150 Hz)
Sensitivity -36±3dB (0dB=1V/Pa,at 1KHz) 1.5V 2.2k
Output Impedance 150 ohm
Maximum Output 10 dBu (at 1 kHz, 1% THD into 1 kOhm)
Dynamic Range 125 dB (per IEC651)
Maximum SPL 110 dB
Signal to Noise Ratio 80 dB SPL (per IEC651)
Power 48V phantom power; built-in lithium battery (battery
life:150 hours)
Output Connection 3-pin XLR, balanced output between Pin 2 (+),
Pin 3 (-) and Pin 1 (ground)
Dimensions 395*23*23 mm
Weight 222g (7.83 oz.)
包装清单
• Soundbird T3L麦克风
• Micro USB线
• SR-SMC1麦克风支架
• SR-SMC3麦克风防震架
• 防风棉
• 60 XLR厘米 线
参数
声学原理 线性梯度
拾音模式 超心型
频率响应 35-20kHz (低切功能 75/150 Hz)
灵敏度 -36±3dB (0dB=1V/Pa,at 1KHz) 1.5V 2.2k
输出阻抗 150 ohm
最大输出 10 dBu (at 1 kHz, 1% THD into 1 kOhm)
动态范围 125 dB (根据 IEC651)
最大声压级 110 dB
信噪比 80 dB SPL (根据 IEC651)
供电方式
输出接口 3针卡侬口
尺寸 395×23×23 mm
重量 222g
供电方式 内置锂电池 48V幻象电源 低电量
指示灯状态 蓝灯 绿灯 红灯
特点
-10dB衰减
衰减麦克风输入电平，防止输入电平过高导致破音
75Hz/150Hz低切过滤器
减少低频噪音的收录，如空调，街道车声等。
高频增益功能
佩戴防风毛的过程中，部分高频声无法收录; 开启高频增益功能，录制清晰的声
音。
可充电内置锂电池
150小时工作时长
电量指示灯
如果在录像过程中想查看电池电量，双击电源按钮，5个指示灯将显示剩余电量。
满电量：5个指示灯全为蓝色。
配备防风棉，麦克风支架，防震架，XLR输出线，MicroUSB充电线
电源指示灯
内置锂电池或48V幻象电源供电
48V幻像电源；内置锂电池（电池寿命：150小时）
