VGA to HDMI Converter
VGA TO HDMI CONVERTER THAT
SUPPORTS STEREO AUDIO IN
AND INFRARED DEVICES
Quick Start Guide
VGA VIDEO IN
Format VGA
Resolution 480i, 480p, 576i, 576p, 720p,
1080i, 1080p (24/25/30Hz
DDC Via AUX
Input Equalization Automatic
Input Cable Length Up to 25 ft
Output Cable Length Up to 25 ft
HDMI VIDEO OUT
Format HDMI 1.3 Supported
HDCP Compliance 1.0/1.1
Video Bandwidth Single-link 340MHz (10.2 Gbps)
Resolution 480i, 480p, 720i, 720p, 1080i,
1080p (24/25/30Hz)
Output Interface (1) HDMI (7.1 Channel audio and
video)
Connector Type A (19-Pin Female)
Maximum Distance Up to 25 ft
AUDIO
Signal Type DTS-HD/Dolby-TrueHD/LPCM7.1/
DTS/Dolby-AC3/DSD
Input Interface (1) 3.5mm Audio In (Female)
OTHER
Power External 100-240 VAC/5VDC4A
@10W
Dimensions 2.5” W x 7/8” H x 2 1/4” D
Weight 0.5lb per V2 unit
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
CVH-01
WHAT’S IN THE BOX
PART NO. DESCRIPTIONQ-TY
CVH-01 1 VGA to HDMI Converter
PS5VDC2A 1 PS5VDC2A Power Supply
Quick Start Guide 1
OVEVIEW
The CVH-01 V2 converts analog VGA Video and audio to
HDMI. The CVH-01 V2 is the perfect solution for Home
Theater, PC networking, conference center systems, point
of sale, camera surveillance and much more. Setup and
installation is simple to follow and requires no additional
software to complete. The CVH-01 V2 connects old systems
to newer HDMI displays, converts analog video signals to
digital HDMI signals; it can even be used as VGA to HDMI
converter!
FEATURES
• Connects old systems to newer HDMI displays
• Can be used as VGA to HDMI converter
• Highly precise 10-bit A/D conversion of each color
channel
• Ensures to send high-denion signal without signal
loss
• Supports Plug-and-play funcon, no soware
installaon required
• Supports single high-denion display for mulple
sources
1. Connect a VGA video and audio input device.
2. Connect an HDMI display to the HDMI output on the CVH-01 V2.
3. Connect the power cord to the CVH-01 V2.
4. Power on the input, the device and the display.
HARDWARE INSTALLATION
CVH-01 V2 FRONT PANEL
VGA IN
AUDIO IN
HDMI OUT
CVH01
