Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned
herein.
Microphone Lav-S6M2 User Manual
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
① Power Button & Low Cut
② Type-C Charging Port
Please fully charge the microphone
before use.
③ Working Indicator
④ Gain Control
Adjust the gain as per actual
recording.
⑤ 3.5mm Monitoring Jack
Plug the headphones in to real-
time monitor the recording.
⑥ Mode Switch
Choose the corresponding mode
based on your device.
Product Instruction
Operations
1. The Use of Wind Mu󽗈 & Tie Clip
2. The Use of Microphone
Green Light
Working
Blue Light
Charging (The light
is o󽗈 when it is fully
charged.)
Light O󽗈
Low Battery
IncreaseDecrease
Cameras
Camcorders
Mixers
Recorders
3.5mm to 6.3mm
AdapterComputers (with separate mic &
earphone jack)
Android Phone (3.5mm Jack);
iPhone
iPhone (iPhone 7
and subsequent versions)
Android Phone (Type-C Port)
Lightning Adapter
(excluded)
Power O󽗈
Power On
Phone
Mode
Low Cut On
Camera
Mode
Type-C Adapter
(excluded)
Camera ModePhone Mode
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its
operation speci󽗉cation
Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking
Modi󽗉cations to a product by its user or a third party without prior written
consent of SYNCO, e.g. replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certi󽗉cate, or the
code on the product or warranty certi󽗉cate is altered or torn o󽗈
All consumable accessory attached to a product, like cable, wind mu󽗈, battery
Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact
a local agent for assistance, or you can always contact SYNCO’s customer
service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certi󽗉cate as proof of purchase.
If any of these documents is missing, only sales return or chargeable service
will be provided.
If the SYNCO product is out of the warranty coverage, the service and the parts
cost will be charged.
Transducer
Frequency Response
Signal/Noise
Sensitivity
Max SPL
Gain Range
Low Cut
Output Impedance
Headphone Connector
Audio Cable
Output Connector
Battery Requirement
Battery Charging Time
Battery Life
Dimensions (L x Diam)
Weight
Condenser
20Hz-20KHz
79dB
-32dB +/-3dB/ 0dB=1V/Pa,1KHz
110dB
9dB
150Hz
1000Ω
3.5mm TRRS
6 Meters/19.7 Feet
3.5mm TRRS
400mAh Built-in Battery
1.5H
40H (Audio Monitoring O󽗈)
30H (Audio Monitoring On)
60×33.8×17mm
67g
2. Performance Parameter
Warranty Period
Thank you for purchasing SYNCO products.
Warranty
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us
via Email：support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
Speci󽗉cations
1. Polar Pattern: Omni-directional
1. Customers are entitled to free replacement or repair service in case of quality
defect(s) found in the product under normal use within 30 days upon receipt of
the product.
2. Original SYNCO products are entitled to limited warranty service. 12-month
The warranty period begins on the date of purchase of brand new, unused
products by the 󽗉rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
