Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned
herein.
Microphone Mic-M1S User Manual
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
1. Insert the microphone body into
the shock mount. Make sure it is
secure and well-balanced.
Operations
2. Install the windshield to the front of
the microphone body.
4.Open the audio or video recording application on your device and begin
recording.
3. Connect the microphone with your device via corresponding output cable.
For camera series (camera, camcorder, audio recorder, and other audio/
video recording devices)
For phone series (smartphone, tablet, Mac)
① Attach the shock mount to the camera via the cold
shoe.
② Connect the microphone with the device via the
3.5mm TRS camera cable.
① Attach the shock mount to smartphone holder
(exclusive) via the cold shoe or thread.
② Connect the microphone with the device via the
3.5mm TRRS phone cable.
Camera Settings
As a plug-and-play microphone, M1S requires built-in power through the
microphone input of your camera. For the best performance, please set the
audio input of your camera as below.
Audio Input: Microphone Input
Audio Level/Gain Control: Manual (if possible)
Plug-in Power: Power On
Refer to the instructions provided with your camera for setup on audio
settings.
Speci󽗉cations
1. Polar Pattern: Cardioid
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its
operation speci󽗉cation
Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact
a local agent for assistance, or you can always contact SYNCO’s customer
service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certi󽗉cate as proof of purchase.
If any of these documents is missing, only sales return or chargeable service
will be provided.
If the SYNCO product is out of the warranty coverage, the service and the
parts cost will be charged.
Transducer
Polar Pattern
Frequency Response
Signal/Noise
Max. SPL
Sensitivity
Power Requirement
Connector
Dimensions
Net Weight
Condenser
Cardioid
100Hz-20KHz/ ±3dB
＞60dB
130dB@1KHz, 1%THD
-35dB re 1 Volt/pasal(18.00mV@94dB SPL )
+1/-2dB@1KHz
Plug-in Power
3.5mm TRS/3.5mm TRRS
Φ21.5x 72mm
35g
2. Performance Parameter
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality
defect(s) found in the product under normal use within 30 days upon receipt of
the product.
2. Original SYNCO products are entitled to limited warranty service. 12-month
The warranty period begins on the date of purchase of brand new, unused
products by the 󽗉rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
Warranty
Modi󽗉cations to a product by its user or a third party without prior written
consent of SYNCO, e.g. replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certi󽗉cate, or the
code on the product or warranty certi󽗉cate is altered or torn o󽗈
All consumable accessory attached to a product, like cable, wind mu󽗈, battery
Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning, etc.
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us
via Email：support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
