Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned
herein.
Microphone G1(A2) User Manual
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Package List
RX Receiver x1 TX Transmitter x2 Carrying Bag x1
3-in-1 Charging Cable x1
External Lav Mic (With Wind Mu󽗈) x2
3.5mm TRRS Phone Cable x1
3.5mm TRS Camera Cable x1
Product Instruction
TX Transmitter
RX Receiver
① External Mic Input
② USB-C Port
③ Power
④ Reset(Help with Eject Pin)
⑤ Low Cut
① USB-C Port
② Power(Mono/Stereo Switch)
③ Reset(Help with Eject Pin)
④ Channel A Gain Control
⑤ Channel B Gain Control
⑥ Pairing
⑦ Built-in Mic
⑧ Pocket Clip
⑨ Pairing Indicator
⑩ Power Indicator
⑥ 3.5mm Audio Output
⑦ 3.5mm Monitoring Jack
⑧ Pocket Clip
⑨ Pairing Indicator
⑩ Power Indicator
1.Power Button
Long press the power button for 2 seconds to turn on/o󽗈 the system.
Short press the power button on the RX for Mono/Stereo switch.
2.Pairing
The system will pair automatically after power on. If you need manual
pairing, long press the channel A gain control and channel B gain control
on the RX, and the pairing button on the TX, the system will start to pair.
3.Connection
The receiver outputs audio signals to recording devices with a 3.5mm
TRRS Phone Cable or a 3.5mm TRS Camera Cable. Please use the
corresponding cable based on your device.
4.Installation
Attach the transmitter or the external mic to the speaker’s clothing. Install
the receiver to the camera’s hot shoe via the pocket clip.
( When using the external mic, please insert it into the mic input Note:
properly.)
Operations
Indicator
Slow Flashes
Fast Flashes
Keeps On
Fast 󽗊ashes twice, is
o󽗈 and repeats
Power Indicator (Green)
Power is lower than 10%.
/
It stays green when charging
and is o󽗈 after fully charged.
/
Pairing Indicator (Blue)
Power on
System pairing
System paired
Low cut function is on.
5.Gain Control
The initial value of the gain is the microphone’s original volume. Each
press of the gain control button increases the gain by one level, fourth
level at most. When the gain is at max level, press once and return to
Mic Windshield x1
Eject Pin x1
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us
via Email：support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
Speci󽗉cations
Wireless Transmission
RF Frequency Band
Working Distance
Latency
Mounting
Audio Input
Audio Input Level
RF Output Power
Power Requirements
Battery Type
Battery Charging Time
Battery Life
Dimensions
Material
Weight
Digital 2.4GHz
2400-2483.5MHz
164ft/50m (LOS area), 98ft/30m (NLOS area)
12.5ms
Pocket Clip
1/8" / 3.5 mm TRS Mic Input
1V (0dBV)
＜10mW
3.3V-4.7V
Built-in Lithium Battery
1.5H
8H
52X42X16mm
Plastic
35g
TX Transmitter
initial value.
6.Charging
Please fully charge the TX and RX via the USB-C port and the charging
cable before use.
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its
operation speci󽗉cation
Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking
Modi󽗉cations to a product by its user or a third party without prior written
consent of SYNCO, e.g. replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certi󽗉cate, or the
code on the product or warranty certi󽗉cate is altered or torn o󽗈
All consumable accessory attached to a product, like cable, wind mu󽗈,
battery
Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact
a local agent for assistance, or you can always contact SYNCO’s customer
service through email at support@syncoaudio.com.
Please retain your sales receipt and warranty certi󽗉cate as proof of purchase.
If any of these documents is missing, only sales return or chargeable service
will be provided.
If the SYNCO product is out of the warranty coverage, the service and the
parts cost will be charged.
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality
defect(s) found in the product under normal use within 30 days upon receipt of
Warranty
Wireless Transmission
RF Frequency Band
Approximate RF Sensitivity
Working Distance
Form Factor
Sound Field
Polar Pattern
Frequency Range
Sensitivity
Maximum SPL
Digital 2.4GHz
2400-2483.5MHz
-81dBm
164ft/50m (LOS area), 98ft/30m (NLOS area)
Built-in/External Mic
Mono
Omnidirectional
50Hz-20KHz
-40dB (±3 dB, re 1V/Pa at 1KHz)
135dB SPL (at 1KHz)
RX Receiver
Microphone
Latency
Mounting
Number of Audio Channels
Audio Output
Gain
Audio Output Level
Power Requirements
Battery Type
Battery Charging Time
Battery Life
Dimensions
Material
Weight
12.5ms
Pocket Clip
2
1/8" / 3.5 mm TRS Mic Output
1/8" / 3.5 mm TRS Headphone Output
0-4 Level (0 to 8dB)
Line Out: 1V, Monitoring: 25-30mW
3.3V-4.7V
Built-in Lithium Battery, 400mAh
1.5H
8H
52X42X16mm
Plastic
35g
the product.
2. Original SYNCO products are entitled to limited warranty service. 12-month
The warranty period begins on the date of purchase of brand new, unused
products by the 󽗉rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
