Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned
herein.
Microphone WMic-TS User Manual
Caring For Your SYNCO Product
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Transmitter
Receiver
Screen Display
Product Instruction
Speci󽗉cations
Transmitter (TX)
Receiver (RX)
① 3.5mm Mic Input
② IR Indicator
③ Built-in Mic
④ Function Selection Button △
⑤ Function Selection Button ▽
⑥ OLED Screen
① 3.5mm Audio Output Socket
② IR Indicator
③ 3.5mm Audio Monitoring Socket
④ Function Selection Button △
⑤ Function Selection Button ▽
⑥ OLED Screen
⑦ Menu
⑧ Power Button
⑨ Antenna
⑩ Belt Clip
⑪ Type-C Port
⑫ Reset (Help with Eject Pin)
⑦ Menu
⑧ Power Button
⑨ Antenna
⑩ Belt Clip
⑪ Type-C Port
⑫ Reset (Help with Eject Pin)
Channels
Group A Wireless Frequency
Group B Wireless Frequency
Working Distance
Latency
RF Output Power
Stray Radiation
Input
Low-cut Filter
Battery
Working Time
Charging Time
Antenna
Dimensions
Weight
Operating Temperature
Storage Temperature
60
525.000MHz~539.750MHz
540.000MHz~554.750MHz
150m (LOS), 80m (NLOS)
＜20ms
15dBm
<-60dBc
Built-in Mic/External Mic
100Hz
1300mAh Rechargeable Li-ion Battery
8.5H
3H
PCB Antenna
75.5×64×21.5mm
62g
-20℃~70℃
-20℃~70℃
◆ Transmitter (TX)
Signal Strength High
Group A
Group B Muting
Normal Recording
Muting（Locking）
Muting（Unlocking）
Power Indicator
Audio Dynamic Display Bar Channel Frequency
Signal Strength Low
Group A/B
Channel
Group A Signal Strength
Display Bar
Group B Signal Strength
Display Bar
Power Indicator
Group A Receiving Audio
Status Indicator
Group B Receiving
Audio Status Indicator
Group A
Frequency
Group BChannel of Group A
Group A Transmitter Power
Group B Transmitter
Power
Channel of Group B
Frequency
Please unfold the TX & RX antennas when using for optimal performance.
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us
via Email：support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its
operation speci󽗉cation
Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking
Modi󽗉cations to a product by its user or a third party without prior written
consent of SYNCO, e.g. replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certi󽗉cate, or the
code on the product or warranty certi󽗉cate is altered or torn o󽗈
All consumable accessory attached to a product, like cable, wind mu󽗈,
battery
Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact
a local agent for assistance, or you can always contact SYNCO’s customer
service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certi󽗉cate as proof of purchase.
If any of these documents is missing, only sales return or chargeable service
will be provided.
If the SYNCO product is out of the warranty coverage, the service and the
parts cost will be charged.
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality
defect(s) found in the product under normal use within 30 days upon receipt of
the product.
2. Original SYNCO products are entitled to limited warranty service. 12-month
The warranty period begins on the date of purchase of brand new, unused
products by the 󽗉rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
Warranty
Group A Wireless Frequency
Group B Wireless Frequency
Working Distance
Latency
Receiving Sensitivity
Stray Radiation
SNR
Audio Output Jack
Audio Output
Volume (Gain)
Battery
Working Time
Charging Time
Antenna
Dimensions
Weight
Operating Temperature
Storage Temperature
Form Factor
Sound Field
Polar Pattern
Frequency Range
Sensitivity
525.000MHz~539.750MHz
540.000MHz~554.750MHz
150m (LOS), 80m (NLOS)
＜20ms
-95dBm
<-60dBc
88dB
1 x 1/8” / 3.5 mm TRS Line Out
1 x 1/8” / 3.5 mm TRS Headphone Output
Mono/Stereo
15 Levels Adjustable Volume
1300mAh Rechargeable Li-ion Battery
8.5H
3H
PCB Antenna
75.5×64×21.5mm
72g
-20℃~70℃
-20℃~70℃
1 x 1/8" / 3.5 mm TRS Male Unbalanced (Lockable)
Mono
Omni-directional
20Hz-20KHz
-38dB
◆ Receiver (RX)
◆ External Lavalier Microphone
