Page 2
G-Max™ 200 Manual Rev. B © 2021 Blizzard Lighting, LLC
TABLE OF CONTENTS
G-Max™ 200 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2. Meet The G-Max™ 200 5
Main Features 5
DMX Quick Reference 5
The G-Max™ 200 Pin-up Picture 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch Of G-Max™ 200 Fixtures 7
Data/DMX Cables 7
Cable Connectors 8
3-pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
Mounting Points 10
Clamp Mounting 11
Securing the Fixture 11
4. Operating Adjustments 12
The Control Panel 12
Control Panel Menu Structure 13
DMX Channel Values In-Depth 15
Gobo Replacement 16
Rotating Gobos 16
Static Gobos 16
5. Appendix 17
Keeping Your G-Max™ 200 As Good As New 18
Returns (Gasp!) 18
Shipping Issues 18
Tech Specs 19
Troubleshooting 18
Dimensional Drawings 19
Photometric Data 19
Page 3
G-Max™ 200 Manual Rev. B © 2021 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• G-Max™ 200 Fixture
• An Ever-So-Handy Power Cord
• 2 x Mounting Brackets
• 1 x DMX Cable
• 1 x Safety Cable
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on purchasing the G-Max™ 200 professional LED moving head xture!
Now that you’ve got your G-Max™ 200, you should carefully unpack the box and check the
contents to ensure that all parts are present and in good condition. If anything looks as if it
has been damaged in transit, notify the shipper immediately and keep the packing material
for inspection. Again, please save the carton and all packing materials. If a xture must
be returned to the factory, it is important that the xture be returned in the original factory
box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the
xture you receive is suitable for your local power supply. See the label on the xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something happens to go wrong, please visit www.blizzardpro.com/support and open a
support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are subject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 11/5/2019 J. Thomas 11/17/2021
