Sida 1/20
Page 2
Motif Fresco™ User Manual Rev. C (c) 2017 Blizzard Lighting, LLC
TABLE OF CONTENTS
Motif Fresco™ 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t run with scissors!) 4
2. Meet The Motif Fresco™ 5
Features 5
DMX Quick Reference 5
The Motif Fresco™ Pin-up Picture 6
3. Setup 7
Connecting A Bunch Of Motif Fresco™ Fixtures 7
Data/DMX Cables 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
4. Operating Adjustments 10
Navigating The Control Panel 10
Control Panel Menu Structure 11
DMX Mode 11
Setting the DMX Address 11
Setting the DMX Channel Mode 11
Slave Mode 11
Dimming Mode Settings 12
Custom Programs 12
Auto Mode and Auto Speed 12
Color Calibration Settings 13
Custom Static Colors 13
Fixture Reset Functions 13
Data Sync Feature 13
Using the IR Remote Control 14
DMX Channel Values In-Depth 15
Dimensional Drawings 15
5. Appendix 16
A Quick DMX Lesson 16
Troubleshooting 16
Keeping Your Motif Fresco™ As Good As New 17
Returns (Gasp!) 17
Shipping Issues 17
Tech Specs 18
Page 3
Motif Fresco™ User Manual Rev. C (c) 2017 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Motif Fresco™ LED Fixture
• 1 x DMX Signal Cable
• 1 x IP Rated AC Power Cord with Cable Cap
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on purchasing one of the brightest, cutest little outdoor rated xtures
anywhere! Now that you’ve got your Motif Fresco™ (or hopefully, Fresco’s!), you should
carefully unpack the box and check the contents to ensure that all parts are present and
in good condition. If anything looks as if it has been damaged in transit, notify the shipper
immediately and keep the packing material for inspection. Again, please save the carton
and all packing materials. If a xture must be returned to the factory, it is important that
the xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the
xture you receive is suitable for your local power supply. See the label on the xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something happens goes wrong, please visit www.blizzardlighting.com/
support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are subject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardlighting.com.
Author: Date: Last Edited: Date:
J. Thomas 12/9/2013 J. Thomas 11/16/2017
