BG-UMV-HA41
4K 4X1 Seamless Switcher Multiview/ er
All Rights Reserved
User Manual
Table of Contents
1. Product Introduction .................................................................................................... 1
1.1 Features ............................................................................................................. 1
1.2 Package List ....................................................................................................... 1
2. Specification ................................................................................................................ 2
3. Panel Description ........................................................................................................ 4
3.1 Front Panel ......................................................................................................... 4
3.2 Rear Panel ......................................................................................................... 5
4. System Connection ..................................................................................................... 6
5. Front Panel Control ..................................................................................................... 7
5.1 Multi-views Selection .......................................................................................... 7
5.2 Video Signal Switching ....................................................................................... 7
5.3 Video Switching Status Inquiry ........................................................................... 8
5.4 Audio Select ....................................................................................................... 8
5.5 Config Button ..................................................................................................... 8
6. IR Remote ................................................................................................................... 9
7. GUI Control................................................................................................................ 10
7.1 Multiview Tab .................................................................................................... 11
7.2 Audio Tab ......................................................................................................... 13
7.3 Resolution Tab ................................................................................................. 14
7.4 RS232 Tab ....................................................................................................... 14
7.5 CEC Tab ........................................................................................................... 15
7.6 EDID Tab .......................................................................................................... 17
7.7 Network Tab ..................................................................................................... 18
7.8 Tags Tab ........................................................................................................... 19
7.9 Security Tab...................................................................................................... 19
7.10 GUI Update .................................................................................................... 20
8. RS232 Control ........................................................................................................... 21
8.1 System Control ................................................................................................. 21
8.2 Signal Switching ............................................................................................... 22
8.3 Audio Switching ................................................................................................ 23
8.4 Function Setting ............................................................................................... 24
8.5 CEC Command ................................................................................................ 28
8.6 Special Command ............................................................................................ 31
9. Firmware Upgrade ..................................................................................................... 33
10. Warranty .................................................................................................................. 34
11. Mission Statement ................................................................................................... 34
1
1. Product Introduction
The 4K Multi-view switcher is seamless video scaler designed to enable a true 4K
display. The switcher features four HDMI inputs and one HDMI output which allows you
to display four video sources on one display. It also provides a line input, 1 mix input, 1
SPDIF output and 1 analog output for audio processing.
Control is quick and comprehensive, whether you are using the front panel, the remote
control, RS232 commands, or the fully featured web GUI.
1.1 Features
4 HDMI inputs, 1 HDMI output.
Supports 4K@30Hz 4:4:4, HDCP 2.2.
Seamless switch between 4 input ports.
Auto Scaler in each source input.
Supports audio embedding and mixing.
Supports audio de-embedding.
Auto-switching at single window.
Cycles through the windows from A to D by swap button.
Base on FPGA Technology, layout and size of the windows can be customized.
Resizes the windows in 3 different sizes.
16 pre defined layouts for multi- -view.
Multiple control methods, including an assignable front panel, IR remote, web GUI
and RS232 port.
1.2 Package List
1x 4K 4x1 Seamless Switcher
1x IR Remote
4x Plastic Cushions
2x Mounting Ears
4x Mounting Screws
2x 3-pin Terminal Block
1x RS232 Cable (3 pin to DB9)-
1x Power Adapter (24V DC 1.25A)
1x User Manual
Note: Please contact your distributor immediately if any damage or defect in the
components is found.
