Sida 1/20
BZ-MVS8x8- 4K
8x8 Seamless UHD Matrix
Warning
⚫ Do not expose this device to Rain, Moisture, and Dripping
⚫ Only use accessories specified by the manufacture
⚫ Unplug this device during Lightning Storms
⚫ Product specifications may be subject to technical upgrades without further
notice
1. Introduction
BZ-MVS8x8- is a seamless UHD matrix switcher with HDMI inputs and 8x HDMI outputs4K 8x .
Audio extract or insert can also enabled on this device. IR matrix routing on this video be
matrix is followed with video routing.
Key Features:
⚫ Supports HDMI 2.0/HDCP 2.2
⚫ Supports seamless switching
⚫ Supports IR matrix
⚫ Supports HDMI audio extract
⚫ Supports external LR audio insert on HDMI stream
⚫ Supports EDID management
⚫ HDMI video output resolution:
3840x2160@60, 3840x2160@30,1920x1080@60,1280x720@60,
1920x1200@60,1360x768@60,1280x1024@60, 1024x768@60
⚫ Front panel, RS232, TCP/IP (LAN 10M/100M) control
2. Front Panel Control
⚫ OUTPUT/INPUT buttons
Press buttons OUTPUT n + INPUT m+ TAKE by sequence, user can switch matrix routing
⚫ Press button POWER, to make the matrix enter or release standby state. When standby,
the power LED will be light ed
⚫ Press button LOCK, to lock or un-lock front buttons. When locked, the Lock LED will be
lighted
⚫ Press buttons ALL + INPUT m + TAKE by sequence, to switch input to all the outputs m
⚫ Press button SAVE + OUTPUT n to save current routing scene as scene n. The maximum
allowable scene No. is 8
⚫ Press button RECALL + OUTPUT n to recall routing scene n as current routing
⚫ Press buttons RES + OUTPUT n + NEXT + TAKE, to change output resolution of OUTPUT n
port
Resolution options :
3840x2160@60, 3840x2160@30,1920x1080@60,1280x720@60,
1920x1200@60,1360x768@60,1280x1024@60, 1024x768@60
⚫ Press buttons EDID + INPUT m + NEXT + TAKE, change the EDID mode of port INPUT m
EDID option: Manual,3840x2160@60, 3840x2160@30, 1280x1024@60
1920x1080@60,1280x720@60,1920x1200@60
