ACPLX-12Y
Smart-Play Integration with Multi Camera Inputs
for Select 2013-2019 Lexus Vehicles without OEM Navigation
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.061220
1 of 8
- Smart-Play Integraon system allows connecon of Android and other phones to the Lexus infotainment system.
- Made for Android Auto and CarPlay.
- Adds front and rear aermarket camera inputs.
- Retains funconality of the OEM backup camera if present.
- Front camera automacally shows on the screen aer changing the gear from reverse to drive.
- Ulizes factory microphone for voice controls.
- Uses the factory Jog Wheel and steering wheel control buons for Smart-Play controls.
PRODUCT FEATURES:
ACPLX-12Y Module Main Harnesses Smart-Play Interface Module
OSD Controller GVIF Video Cables 4K HDMI Cable USB Extension Cable
PARTS INCLUDED:
Jog Wheel Controls Steering Wheel Controls
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0612202 of 8
WIRING DIAGRAM:
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MAIN
ACPLX-12Y
Smart-Play / Android Auto Integration
for Lexus Vehicles without Nav
IN TE RFACI NG SO LU TIO NS
REAR CAMERA
FRONT CAMERA
OSD
CONTROL
PAD
OSD Control Pad is used to
adjust the settings. Must be
unplugged and stored after use.
Multi/IO
HDMI
Smart-Play Module
INTERFACING SOLUTIONS
HDMI
Power Port
Original Smartphone
Cable To Smartphone
GVIF
IN
GVIF
OUT
To the 24-pin connector
behind factory radio
From the 24-pin connector
behind factory radio
To factory screen
From factory screen
OUT
IN
Smart-Play
Power
Utilizes factory
microphone
MIC
USB
To the 28-pin connector
behind factory radio
From the 28-pin connector
behind factory radio
Line Out (Aux)
To the 24-pin connector
behind factory screen
From the 24-pin connector
behind factory screen
Tap here for camera power
Red = 12V ACC
Black = Ground
ACPLX-12Y
Smart-Play Integration with Multi Camera Inputs
for Select 2013-2019 Lexus Vehicles without OEM Navigation
DIP SWITCH SETTINGS:
DIP SETTING VEHICLE
1 to 8 ALL OFF CT, GS, RX
4ON (rest OFF) ES, IS, RC
Note: ON is down and OFF is up
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.061220
3 of 8
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
ACPLX-12Y
Smart-Play Integration with Multi Camera Inputs
for Select 2013-2019 Lexus Vehicles without OEM Navigation
On vehicles with a 12.3” screen, you can change the screen resoluon to show 5 horizontal App icons.
Press and hold for 3 seconds
to go to screen sengs mode.
Set “CP” to 1024 x 600 Set “Wheel buon input Only:”
to ON for Android Auto
INSTALLATION INSTRUCTIONS:
NOTE: Connecons are made behind the radio and behind the screen.
1. Remove the trims on both sides of
the center console.
2. Remove the right and le side trim
along the center console.
3. Remove the Jog Wheel console and
uplug the harness.
