Keyscan CIM Link
Global Network
Connectivity Module
A simple way to incorporate multiple CIM communication
loops into a single global infrastructure.
Keyscan CIM-Link is a TCP/IP companion module, which
incorporates multiple CIM CAN Bus communication loops
into a single global infrastructure. This promotes even
greater global communication flexibility. Keyscan’s CIM-Link
module extends CAN Bus based ACU to ACU communica-
tion via a common LAN/WAN network. This maximizes sys-
tem design options by expanding ACU to ACU functionality
to multiple independent CAN Bus global networks utilizing
common LAN/WAN (TCP/IP) infrastructure.
Ground Loop Tolerance
Maximizes electrical isolation to earth ground providing
tolerance against ground loops.
Enhanced Diagnostics
Provides a myriad of communication diagnostics annunciated
with on-board LEDs for quick and easy device-based
troubleshooting.
Network Adaptation
Uses Keyscan’s plug-on TCP/IP network adapter
NETCOM2P/6P
TCP/IP Tunneling
Ensures uninterrupted and re-connect continuous
communication between CIM-Links.
Network Support
Supports global functions between groups of multiple
ACU panels or between a single ACU panel over an
existing LAN/WAN network.
Global Communication
Utilizing the CAN Bus network, the CIM-Link delivers global
communication capabilities. Access Control Units with
direct connectivity with the CAN Bus network now provide
ACU to ACU communication without server dependence.
Ribbon Cable
Uses a simplified ribbon cable for fast installation.
Fault Tolerance
Unlike traditional communication devices, if one Keyscan
CIM-Link goes down due to unforseen circumstances, it
won’t take the entire loop down with it. The CAN Bus
communication protocol offers non-interrupted
communication of remaining devices on the CAN Bus network.
Specifications
dormakaba Canada Inc.
901 Burns St., E.,
Whitby, Ontario
Canada L1N 0E6
1 888 539 7226
www.dormakaba.us KKT2052 2018-07
© dormakaba Canada Inc. (2018). Information on this sheet is intended for general use only. dormakaba Canada reserves the right to alter designs and
specifications without notice or obligation. Printed in Canada.
Operating Voltage 12 VDC
Current Draw (CIM-Link) 290 mA (each)
Dimensions 4 5/8” x 3” (11.7 cm x 7.6 cm)
Operating Environment 32 F - 140 F (0 C - 60 C)
Topology Linear
Network Requires LAN/WAN (TCP/IP) infrastructure
Network support Standard, Encrypted
CAN Bus Requires connection to CAN Bus 2 ACU to ACU global communication
Firmware Minimum EPROM versions 7.40/8.20
Software
Aurora (All)
System 7.0.16 or higher
Vantage 8.1.15 or higher
Typical Applications - Connecting multiple CIM communication loops
