FEATURESTECHNICAL SPECS
Thank you for purchasing Erica Synths Pico Series module!
With Pico Series we challenged ourselves – can we make ANY
superior functionality synth module 3HP wide and affordable?
Erica Pico Trigger module provides master clock for the Pico
System, as well as it generates up to 16 step patterns of 4
triggers – simple clock divider patterns, and more advanced
polyrhythmic patterns of different step length for triggering
drums. Patterns are user designed in custom web interface, and
can be uploaded to the module via CLK in 3,5mm jack.
Selectable internal clock or external clock
Clock output
Polyrhytmic patterns
Adjustable shuffle
4 trigger outputs
8 pattern memory
Web-based pattern design interface
Pattern upload via CLK input
Clock rate 20BPM – 420BPM
Trigger amplitude 5V
Trigger duration 10ms
Power consumption +20mA, -5mA
Module width 3HP
Module depth 35mm
PICO
TRIGGER
TRIGG
PICO
LOAD
OUT
IN
CLK
T1
T2
T3
T4
IN/OUT SWITCH selects Clock
source. out setting means the
module generates internal clock
and outputs it on CLK jack. in
setting means you can patch the
external clock signal in CLK jack.
The module will start to play
sequence as soon the first clock
signal appears.
The encoder allows you to
access main features of the
module. Push the encoder to move
through different modes.
1) If the encoder is blinking GREEN,
it indicates PATTERN PLAY mode
and stets clock rate.
2) If the encoder is light YELLOW,
it sets shuffle amount. Rotate
the encoder to alter shuffle
amount. The brighter is the
encoder, the more shuffle is
applied.
3) To upload patterns from the
web interface, set the IN/OUT
switch to IN setting and then
push and hold the encoder for
2’’. The encoder will blink RED.
Now you can connect a
laptop/tablet/mobile phone
with pattern designer
interface open to CLK jack and
upload pattern to the selected
memory slot. It will take about
second for upload to complete,
and the encoder will blink
green once. Now you can upload
next pattern, etc. Once you
have uploaded all patterns,
push the encoder promptly,
and it will advance to PATTERN
PLAY mode.
NB! DO NOT CONNECT ANY DEVICE
RUNNING “PATTERN DESIGNER”
TO THE “CLK” PORT WHEN THE “CLK”
IS SET TO “OUT”. BY DOING SO YOU
MIGHT DAMAGE YOUR DEVICES AUDIO
OUT PORT.
Patch external clock TO CLK JACK
or send the internal clock to
other modules. Also use this jack
to upload patterns from
web-based pattern
designer interface.
LOAD button allows you to load
trigger patterns from internal
memory on the fly, even during
performance. Once button is
pressed, Trigger Out LEDs will stop
blinking (but module continues to
send trigger signals)AND WILL
INDICATE PATTERN SELECTION. T1-T4
MEANS PATTERNS 0-3 AND BLINKING
T1-T4 SHOWS PATTERNS 4-7.. Rotate
the encoder to select a pattern
and push the encoder to confirm.
Four LEDs indicate the active
Triggers and selected patterns.
T1, T2, T3 T4AND are
Trigger outputs
PICO
TRIGGER
The Pico Trigger pattern design interface allows you to design patterns of four triggers up to 16 ste
1) Use dropdown to select desired track length for each trigger. Combination of different track leng
triggers.
2) Set BPM for your pattern! BPM setting will be saved together with a pattern in selected memory sl
3) Tick boxes to set active steps (active triggers) for each track. Hit PLAY button, and you can listen
second track – snare drum, third – percussion, fourth – hit-hats. You can clear all tracks by click
4) Once you are happy, how pattern sounds, initiate pattern upload mode on Pico Trigger module, conn
dropdown next to UPLOAD to select one of 8 slots, where the pattern will be uploaded, and hit UPLO
will blink green once to signal that the upload has been successful.
5) Now you can design next pattern and upload it to another slot. If you select a slot which already
6) You also can save patterns on your laptop, and load previously saved patterns from it. To do so, u
You can access Pico Trigger pattern design interface on: www.ericasynths.lv/triggergen
