2x1/4x1 4K/18G HDMI Switchers
with Analog & Digital Audio De-Embed Output,
IR, RS-232, IP Control
The Experts in Digital Video Technology and Solutions ™
KD-Pro2x1X KD-Pro4x1X
Table of Contents
Introduction 4 ....................................................................
Quick Setup Guide 2 ...............................................................
Control 4........................................................................
Rack Mounting: 5..................................................................
Application Example 6 ..............................................................
Connections, LEDs, Buttons, Slide Switches, Rotaries 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Integration with KD-AMP220 13.......................................................
IR Remote Control 15...............................................................
TCP/IP & RS-232 Commands 15 ......................................................
Specifications 19..................................................................
Important Product Warnings & Safety Instructions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contacting Key Digital 21............................................................
Warranty Information 21.............................................................
Always follow the instructions provided in this Operating Manual.
KD-Pro2x1X KD-Pro4x1X
Default IP Address: 192.168.1.239
Please visit www.keydigital.com for the latest
product documentation and software downloads.
Product features and specifications are subject
to change without notice.
Introduction
Key Digital® KD-Pro2x1X/KD-Pro4x1X are 4K/18G HDMI switchers with analog and digital audio
de-embedding, auto switching, and app-ready controllability. Designed for professional audio video
installations in conference rooms, huddle spaces, classrooms, theater and gaming spaces, KD-Pro2x1X/
KD-Pro4x1X enables multiple video sources to connect to a single video display while analog (3.5mm &
balanced/unbalanced) and digital (optical & PCM) audio de-embed ports may feed audio of the selected
source into and amplifier, DSP, or sound bar. Integrating KD-Pro2x1X/KD-Pro4x1X with KD-Amp220
will enable an app-ready all-in-one solution for control of video switching with sound and speech
enforcement. KD-Pro2x1X/KD-Pro4x1X HDMI switchers support all SD, HD, VESA and Ultra HD/4K
video standards with HDR header information included in a variety of 4K EDID handshakes. In addition to
IR, RS-232, and TCP/IP control, KD-Pro2x1X/KD-Pro4x1X can also be controlled via trigger voltage and
features status-monitoring LEDs.
1
Key Features
HDMI Switching: 2/4 HDMI sources to 1 HDMI output/display
Ultra HD/4K: Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to
18Gbps bandwidth)
HDCP Licensing: Fully licensed and compatible with HDCP 2.2
HDR10 and Dolby Vision: More life-like images through a greater range of luminance levels
Audio De-embedding: Audio of the selected HDMI input is de-embedded at the analog
(3.5mm stereo & L/R balanced/unbalanced) and digital (optical & PCM) connectors.
Key Digital® App Ready: Scan & detect population for pre-built GUI and TCP/IP control via
Key Digital®
App
KD-AMP220 Control Mode: Command forward to KD-AMP220 for an all-in-one user-friendly
control UI of video switching, audio and speech enforcement
Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected
source via hot plug detection voltage when enabled
Resolution Support: Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) up to
4096x2160p.
Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
Full Buffer System™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to
source & display, and EDID Control handshake
EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in
addition to native EDID data copied from the output/display 1
Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio
™,
and Dolby® Atmos
CEC Pass-thru: From connected display to selected HDMI source
Control: Front panel button, serial IR, optical IR, RS-232, trigger in, and TCP/IP controllable
Control System Support: Key Digital® App ready. Compass Control® Pro ready. Fully controllable by
all IR, RS-232, and TCP/IP supported control systems via open API.
Included Accessories
Power Supply: KD-PS12W5VC 5V/2.4A DC power jack, screw-in type
IR Remote Control: KD-RMSWPROK
6ft USB 2.0 (Micro) to USB A cable
Rack Ears: 1x long, 1x short rack ear for mounting in full-width rack
2x 6-pin terminal blocks for control, analog audio
