o w n e r s m a n u a l
Omnipolar Speaker System
NANOSAT PRESTIGE
S E R I E S
PRINTED IN CHINA
7AI//NANOPR
owners manual
IMPORTANT SAFETY
INSTRUCTIONS –
READ CAREFULLY!
Caution: To prevent the risk of electrical shock, match wide blades of
plug to wide slot, fully insert.
Read Instructions: All safety and operating instructions should be
read before the product is operated.
Retain instructions: Safety and operating instructions should be
retained for future reference.
Heed Warnings: All warnings on the product & operation instructions
should be adhered to.
Follow Instructions: All operating and use instructions should
be followed.
Cleaning: Unplug the product from the wall before cleaning. Do not
use aerosol or liquid cleaners, just a damp cloth.
Attachments: Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
Water and moisture: Do not use this product near water.
Ventilation: Openings in the cabinet are provided for ventilation and
to ensure reliable operation and protect it from overheating so they
must not be blocked or covered by placing the product on a bed, sofa
or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have been adhered to.
Power Sources: This product should be operated only from the type
of power source indicated on the marking label. If you are not sure of
the type of power supply in your home, call your local power company.
Grounding or Polarization: This product may be equipped with a
polarized alternating current line plug. This plug will fit the power
outlet in only one way as a safety feature. If you are unable to insert
the plug, try reversing it. If the plug should still fail to fit, contact your
electrician to replace your outlet. Do not defeat the safety purpose of
the plug.
Power Cord Protection: Power supply cords should be routed
so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs,
convenience receptacles and the point where they exit from the
product.
Overloading: Do not overload wall outlets or extension cords, as this
can result in a risk of electrical shock.
Object and Liquid Entry: Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short out parts that can result in a fire or electrical shock. Never spill
liquid of any kind on the product.
Servicing: Do not attempt to service this product yourself as openings
or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified personnel.
Heat: This product should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
Non-Use Periods: The power cord of the product should be
unplugged from the outlet when left unused for a long period of time.
Damage Requiring Service: The product should be serviced by
qualified personnel when:
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appliance;
or
C. The product has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a
marked change in performance; or
E. Product has been dropped, or the enclosure damaged.
F. If the product does not operate normally by following the
operating instructions.
2
The lightning flash with arrowhead symbol. Within
an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous
voltage” within the products enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
owners manual
MIRAGE NANOSAT
PRESTIGE SERIES
Please take the time to read all of the instructions contained in this
manual to make certain your system is properly installed and
functioning correctly.
Please retain the carton and packing materials for this MIRAGE ®
product to protect it in the event it ever has to be shipped to a service
center for repairs. Product received damaged by a service center that
has been shipped by an end user in anything other than the original
packaging will be repaired, refurbished, and properly packaged for
return shipment at the end user’s expense.
INTRODUCTION
We are proud to welcome you as a new owner of a MIRAGE speaker.
The finest components and materials are manufactured to exacting
standards and tested with sophisticated manufacturing and quality
control techniques to ensure exceptional performance that is superior
to systems costing several times their price. This approach to the
development of the MIRAGE system has resulted in a significant
improvement over other system designs in terms of performance and
aesthetics.
THE NANOSAT PRESTIGE SERIES
The main goal of this series was to provide a product with the most
natural, accurate performance and seamless, home theater blending.
This was accomplished by using MIRAGE’S proprietary OMNIPOLAR ™
technology. OMNIPOLAR™technology produces the same amount of
direct and reflected sound as live events for the most realistic
experience of either music or home theater. Five identical satellites (or
four satellites and the optional NANO CC center channel) for the front,
center and surround channels guarantee the same tonal and timbre
characteristics to further enhance the life-like, OMNIPOLAR ™
experience.
WHAT EXACTLY IS
OMNIPOLAR™?
OMNIPOLAR™technology uses natural room reflections to create
a greater sense of realism. This realism is accomplished by recreating
the same ratio of direct to reflected sound found in nature, 70%
reflected and 30% direct. A traditional speaker can only produce 30%
reflected sound. It is the required additional reflected sound provided
by an OMNIPOLAR™speaker that creates the OMNIPOLAR ™three-
dimensional sound experience.
COMPANY BACKGROUND
MIRAGE loudspeakers and subwoofers are designed and
manufactured by Audio Products International Corp., known
throughout the industry as "API". A Canadian company founded in
1973, API is one of the largest speaker manufacturers in North
America, supplying products to over fifty-five countries worldwide.
The API factory is a modern 165,000 square foot research,
development and manufacturing facility located in Scarborough, a
suburb of Toronto, Canada. More than 280 people are employed in this
state of the art facility, designing, manufacturing, and marketing
MIRAGE transducers, cabinets, amplifiers and crossovers. A talented
research and development team utilizes advanced computer-based
design techniques and three anechoic chambers in an ongoing
development program.
QUICK SET-UP GUIDE
Recommended Connection for Dolby
Digital/DTS/Dolby Prologic II Systems
1. Arrange the 5 NANOSAT Prestige Satellites and a MIRAGE
Subwoofer in a Home Theater configuration: Use one NANOSAT
for the left, center, right, rear left and rear right channels and one
MIRAGE Subwoofer. See Diagram 4 and 5. Alternatively a
NANO CC could be used as center channel.
2. Connect all five satellites with speaker wire to their respective
speaker outputs in back of the amplifier/receiver. Be sure to
respect the polarity of the wire. Connect the speaker wire from
the positive (RED +) terminal on the receiver/amplifier to the
positive (RED+) terminal on the satellite. Connect the negative
(BLACK-) terminal on the receiver/amplifier to the negative
(BLACK-) terminal on the satellite. See Diagram .
3. Connect the subwoofer from the Subwoofer Output on the back
of the A/V Receiver or processor to the input on the subwoofer.
See Diagram 6. Note: if you’re A/V Receiver is not equipped with
a Subwoofer Output, run an additional set of speaker wires from
your A/V receiver’s Left and Right Front speaker outputs to the
High Level Inputs on the back of the subwoofer. See Diagram 6.
4. MIRAGE suggests using the Small setting in the bass
management set-up of your Dolby Digital system for all speakers.
5. MIRAGE suggests setting the bass management crossover of
your A/V Receiver or processor to 120Hz. (Or as close to 120Hz as
possible). If your A/V Receiver or processor does not have a
variable crossover, please proceed to the next step.
6. Balance the sound output of the speakers by using the pink noise
test pattern generated by your A/V Receiver or processor, adjusting
the system so all speakers produce the same output level.
3
