Sida 1/13

INSTALLATION INSTRUCTIONS

EUROPE

Unit 3, The Moorings Business Park,

Channel Way, Longford,

Coventry, CV6 6RH, UK

Phone: +44 (0)24 7664 4105

Fax: +44 (0)24 7664 4165

NORTH AMERICA

3130 East Miraloma Avenue

Anaheim, CA 92806 USA

USA and Canada

Phone: 1.800.368.9700

Fax: 1.800.832.4888

Other Locations

Phone: (001).714.632.7100

Fax: (001).714.632.1044

Elliptical Ceiling Mount for 37˝ to 63˝ Flat Panels

Model: ECM-3763S

9531-007-024-04

ECM-3763S

Page 2 Visit the Premier Mounts website at http://www.mounts.com Installation Instructions

Contact Premier Mounts with any questions:

(800) 368-9700

techsupport@mounts.com

Contents

Warning Statements

PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS MUST BE READ AND

COMPLETELY UNDERSTOOD TO PREVENT PERSONAL INJURY AND PROPERTY DAMAGE. KEEP THESE

INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.

PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS

PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY

UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS,

DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR

IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.

SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE

PROPER SAFETY GEAR AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.

At least two qualied people should perform the assembly procedure. Personal injury and/or property damage can result

from dropping or mishandling the at panel.

Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are

no electrical wires in the ceiling. Cutting or drilling into an electrical line may cause serious personal injury.

Make sure there are no water or natural gas lines inside the ceiling where the mount is to be located. Cutting or drilling into a

water or gas line may cause severe property damage or personal injury.

This product is intended for indoor use only. Use of this product outdoors could lead to product failure and/or serious

personal injury.

Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of

impact.

Weight Capacity

Maximum at panel weight: 175 lbs. THE CEILING STRUCTURE MUST BE CAPABLE OF HOLDING

FIVE (5) TIMES THE WEIGHT OF THE FLAT PANEL AND

MOUNT. IF NOT, THEN THE CEILING STRUCTURE MUST BE

REINFORCED.

INSTALL THE MOUNT ACCORDING TO THE INSTRUCTIONS PROVIDED BY PREMIER MOUNTS. PERFORM ALL

STRUCTURAL REINFORCEMENTS BEFORE ATTACHING THE FLAT PANEL TO THE CEILING MOUNT. USE THE

APPROPRIATE LIFTING DEVICE WHEN LIFTING THE FLAT PANEL INTO PLACE.

Installation Tools. ...................................................................................................................................................... 3

Parts List................................................................................................................................................................... 3

Mounting Hardware. ................................................................................................................................................. 4

Features. .................................................................................................................................................................. 5

Selecting the Appropriate Mounting Hardware. ........................................................................................... 7

Griplate™ Washer Installation. .................................................................................................................... 8

Nylon Spacer Installation. ............................................................................................................................ 8

Flat Panel Installation. .............................................................................................................................................. 9

Cable Management. ............................................................................................................................................... 10

Tilt Positioning. ....................................................................................................................................................... 11

Optional Mounting Congurations and Accessories. .............................................................................................. 11

Technical Specications. ........................................................................................................................................ 12

Warranty ................................................................................................................................................................. 13

Disclaimer. .............................................................................................................................................................. 13
