INSTALLATION INSTRUCTIONS
CREATING POSITIVE CUSTOMER EXPERIENCES
NORTH AMERICA
3130 East Miraloma Avenue
Anaheim, CA 92806 USA
USA and Canada
Phone: 1-800-368-9700
Fax: 1-800-832-4888
Other Locations
Phone: (001)-714-632-7100
Fax: (001)-714-632-1044
EUROPE
Swallow House,
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
Phone: +44 (0) 2476 614700
Fax: +44 (0) 2476 614710
9531-203-C01-03
Universal Low Profi le Flat Mount for 42 to 63 Flat Panels˝ ˝
Model: P4263F

P4263F
Page 2 Visit the Premier Mounts website at http://www.premiermounts.com Installation Instructions
Contact Premier Mounts with any questions:
(800) 368-9700
techsupport@mounts.com
Contents
Warning Statements
Weight Limit
Maximum Flat Panel Weight: 175 lbs.
THE WALL STRUCTURE MUST BE CAPABLE OF
SUPPORTING AT LEAST FIVE TIMES THE WEIGHT OF
THE FLAT PANEL. IF NOT, THE WALL STRUCTURE MUST
BE REINFORCED.
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS MUST BE READ AND
COMPLETELY UNDERSTOOD. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION
FOR FUTURE REFERENCE.
PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE TECHNICIAN MUST BE FOLLOWED, AS OUTLINED
IN THESE INSTALLATION INSTRUCTIONS. FAILURE TO DO SO COULD RESULT IN PROPERTY DAMAGE, SERIOUS
PERSONAL INJURY, OR EVEN DEATH.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE
PROPER SAFETY EQUIPMENT AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS
PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY
UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS,
DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR
IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
At least two qualifi ed people should perform the assembly procedure. Personal injury and/or property damage can result
from dropping or mishandling the fl at panel.
If mounting to wall studs or ceiling studs, make sure that the mounting screws are anchored into the center of the wall studs
or ceiling studs. Use of an edge-to-edge stud fi nder is recommended.
It is recommended that a maximum of plaster board be used when mounting to wooden studs.⅝″
Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there
are no electrical wires in wall. Cutting or drilling into an electrical line may cause serious personal injury.
Make sure there are no water or natural gas lines inside the wall where the mount is to be located. Cutting or drilling into a
water or gas line may cause severe property damage or personal injury.
This product is intended for indoor use only. Use of this product outdoors could lead to product failure and/or serious
personal injury.
Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of
impact.
Weight Limit. ................................................................................................................................................................................. 2
Warning Statements. .................................................................................................................................................................... 2
Installation Tools. .......................................................................................................................................................................... 3
Parts List....................................................................................................................................................................................... 3
Mounting Hardware. ..................................................................................................................................................................... 4
Features. ...................................................................................................................................................................................... 5
Installing the Wall Plate. ............................................................................................................................................................... 6
Introduction. ................................................................................................................................................................... 6
Determining the Mounting Surface................................................................................................................................. 6
Wood Stud Installation. .................................................................................................................................................. 6
Concrete Installation. ..................................................................................................................................................... 8
Steel Stud Installation. ................................................................................................................................................... 9
Installing the Mounting Bracket. ..................................................................................................................................................11
Selecting the Mounting Hardware. ................................................................................................................................11
Universal Washer Installation. ...................................................................................................................................... 12
Universal Spacer Installation........................................................................................................................................ 12
Locking and Leveling Screw Installation. ..................................................................................................................... 13
Lock-It™ Security Barrel Installation (Optional).......................................................................................................................... 14
Attaching the Mounting Bracket to the Flat Panel. ....................................................................................................... 14
Attaching the Flat Panel to the Wall Plate. ................................................................................................................... 15
Mounting Bracket Adjustments. .................................................................................................................................................. 15
Leveling Screw Adjustment. ......................................................................................................................................... 15
Locking Screw Adjustment. .......................................................................................................................................... 15
Utilizing the Security Barrel. ......................................................................................................................................... 16
Technical Specifi cations. ............................................................................................................................................................ 16
Warranty. .................................................................................................................................................................................... 17
Disclaimer ................................................................................................................................................................................... 17

P4263F
Installation Instructions Visit the Premier Mounts website at http://www.premiermounts.com Page 3
Parts List
Installation Tools
The following tools may be required, dependent upon your particular installation. These tools are not provided by
Premier Mounts, but you can purchase them at your local hardware store.
Your Premier Mounts product is shipped with all proper installation hardware and components. Make sure that none
of these parts are missing and/or damaged before beginning installation. If there are parts missing and/or damaged,
please stop the installation and contact Premier Mounts (800) 368-9700.
P4263F Universal Low Profi le Flat Mount Assembly Components
Wall Plate
(Qty 1)
Mounting Brackets
(Qty 2)
M6 Steel Stud Anchors (Qty 6) 5/16˝ ˝ x 3 Lag Bolts (Qty 6)
Thread Depth Indicator
(Qty 1)
Universal Spacers
(Qty 24)
5/16˝ Concrete Wedge Anchors (Qty 6)
5/16˝ Flat Washers
(Qty 6)
Pro Mounting Hardware
Universal Washers
(Qty 6)
M6 x 120mm Screws
(Qty 4)
Security Barrel
(Qty 1)
Pencil Level
¼ Drill Bit for˝
Wood StudElectronic Stud Finder
Socket Wrench Phillips Tip Screwdriver
Tape Measure
Hand Held Drill
Hammer**
5/16˝ Concrete Drill Bit**
Protective Eyewear
* Optional tools for steel stud installations.
** Optional tools for concrete installations.
½ Socket˝
7/ Drill Bit for16˝
Steel Stud*
M10 Socket*
