Single-Stud/Dual-Stud
Short-Throw Projector Wall Mount
Model: EST100/EST200
9530-011-001-0X Rev.1
INSTALLATION INSTRUCTIONS
NORTH AMERICA
1321 S. State College Blvd
Fullerton, CA 92831 USA
USA and Canada
Phone: 1-800-368-9700
Fax: 1-800-832-4888
Other Locations
Phone: (001) 714-632-7100
Fax: (001) 714-632-1044
Page 2 Visit the Premier Mounts website at http://www.mounts.com Installation Instructions
Table of Contents
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR
PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS OR
MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION
OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR
MODIFICATIONS.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE PROPER
SAFETY GEAR AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.
At least two qualied people should perform the assembly procedure. Injury and/or damage can result from dropping or mishandling the
projector.
If mounting to studs, make sure that the mounting screws are anchored into the center of the studs. Use of an edge-to-edge stud nder is
recommended.
Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are no electrical wires in
wall. Cutting/drilling into an electrical line may cause serious injury.
This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.
Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of impact
Contact Premier Mounts with any questions
(800) 368-9700
techsupport@mounts.com
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND COMPLETELY UN-
DERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND PROPERTY DAMAGE. KEEP
THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE REFERENCE.
Make sure there are no water lines inside the wall where the mount is to be located. Cutting/drilling into a water line may cause severe water
damage to the mounting surface.
EST100/EST200
Weight Capacity
Maximum projector weight: 25 lbs. THE WALL STRUCTURE MUST BE CAPABLE OF HOLDING FIVE
(5) TIMES THE WEIGHT OF THE PROJECTOR. IF NOT, THEN THE
WALL STRUCTURE MUST BE REINFORCED.
Warning Statements
Heading 1
Weight Capacity 2
Warning Statements 2
Installation Tools 3
Parts List 3
Features 4
Determining the Installation Height 5
Wood Stud Installation 6
Throw Distance Calculation 10
Projector Installation 10
Attaching the Mount Carriage 11
Multiple Mounting Point Installation 12
Single Mounting Point Installation 14
Attaching the Mount Carriage to the Projector Arm 15
Cable Routing (Optional) 16
Securing the Projector (Optional) 16
Mount Adjustment 17
Technical Specications 17
Warranty 18
Disclaimer 18
Installation Instructions Visit the Premier Mounts website at http://www.mounts.com Page 3
Projector Arm
(Qty 1)
Mount Carriage
(Qty 1)
Phillips Screwdriver ⅛˝ Drill Bit Electronic Stud Finder
Drill Level
Dual-Stud Back Plate
(Qty 1)
EST100/EST200
Back Plate Hardware Pack (included only with the EST200)
Parts List
Installation Tools
The following tools may be required depending upon your particular installation. They are not included.
Make sure your Premier Mounts product has the following hardware and components before beginning installation. If
there are parts missing and/or damaged, stop the installation and call Premier Mounts at (800) 368-9700.
EST100/EST200 Hardware
M2.5 x 8mm
Security Screw (Qty 4)
M2.5 x 10mm
Security Screw (Qty 4)
M3 x 16mm
Security Screw (Qty 4)
M3 Flat Washer
(Qty 4)
M4 x 12mm
Security Screw (Qty 4)
M5 x 10mm
Security Screw (Qty 3)
M5 x 12mm
Security Screw (Qty 4)
M6 x 12mm Security
Screw (Qty 4)
#14 x 2” Wood Screw
(Qty 2)
¼-20 x 5/16″ Security
Screw (Qty 1)
M5 Security Wrench
(Qty 1)
Barrel Cap
(Qty 4)
M5 x 10mm
Security Screw (Qty 2)
#14 x 2” Wood Screw
(Qty 2)
M5 Flat Washer
(Qty 4)
Sleeve Bushing
Nylon (Qty 4)
Projector Arm
Cover Plate (Qty 1)
