INSTALLATION INSTRUCTIONS
FLIP
Flip-Down LCD Mount
NORTH AMERICA
3130 East Miraloma Avenue
Anaheim, CA 92806 USA
USA and Canada –
Phone: 800-368-9700
Fax: 800-832-4888
EUROPE
Swallow House,
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
Phone: +44 (0) 2476 614700
Fax: +44 (0) 2476 614710
Other Locations – Phone: (001)-714-632-7100; Fax: (001)-714-632-1044
©Premier Mounts 2009
9531-017-011-00
Page 2 Installation Instructions
Table of Contents
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS
PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED
ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS,
ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELAT-
ING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
THE WALL STRUCTURE MUST BE CAPABLE OF SUPPORTING AT LEAST 5 TIMES THE WEIGHT OF THE FLAT PANEL. IF
NOT, THE WALL STRUCTURE MUST BE RE-INFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE
TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD
RESULT IN SERIOUS PERSONAL INJURY, OR EVEN DEATH.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF THIS PRODUCT. USE PROPER
SAFETY GEAR AND TOOLS FOR THE INSTALLATION PROCEDURE TO PREVENT PERSONAL INJURY.
Warning Statements
Indicates that the power plug is to be disconnected
from the power outlet.
Safety precautions must be taken at all times.
Warning and Caution statements.
Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to do so could result in damage to the fl at panel
and/or damage to the mounting surface.
Do not install near heater, fi replace, direct sunlight, air conditioning or any other source of direct heat energy. Failure to do so may result in
damage to the fl at panel and could increase the risk of fi re.
At least two qualifi ed people should perform the installation procedure. Injury and/or damage can result from dropping or mishandling the
fl at panel.
Contact Premier Mounts with any questions -
(800) 368-9700.
Warning Statements 2
Parts List 3
Installation Tools 3
FLIP Mount Location 4
Hardwood Cabinet Installation 5
Softwood Cabinet Installation 6
Mount Installation - Wall Surface (Optional) 7
Attaching the Flat Panel 8
FLIP Mount Adjustments 9
Final Adjustments 9
Technical Specifi cations 10
Warranty 11
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND
COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY AND
PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE
REFERENCE.
It is recommended that a maximum of 5/8” plaster board be used when mounting to wooden studs.
FLIP Mount
Installation Instructions Page 3
Parts List
M5 x 10mm Flat Head Screw (Qty 1)
Flip Mount (Qty 1)
M4 x 10mm Combo Screw (Qty 4)
1/4-20 x 5/8” Combo Screw (Qty 2)
1/4-20 Tee Nut (Qty 2)
#14 x 2” Wood Screw (Qty 2)
Wall Stud Applications
#14 x 7/8” Wood Screw (Qty 2)
Under-counter Applications
FLIP Mount
Congratulations on the purchase of your new Premier Mounts FLIP fl at panel mount. This mount is shipped with all
proper installation hardware and components. Make sure that none of these parts are missing and/or damaged before
beginning installation. If there are parts missing and/or damaged, please stop the installation and contact Premier Mounts
(800) 368-9700.
Installation Tools (not supplied)
Screwdriver
1/8” Drill Bit
(Wood Stud Installation) Electronic Stud Finder Drill
Tape
Measure
Hammer
5/32” Allen Wrench
Pencil
5/16” Drill Bit
(Tee Nut Installation)
The M5 fl at head screw will prevent
the FLIP mount mounting plate from
rotating 360°.
